ASCENDU 3x3

To make a reservation click here

_14A8427 RED.jpg

Specifications

Frame:       butted tubing Reynolds/Columbus, aerospace grade 4130, 6082T6.   Breakable. Rear frame is 27.5, 27.5+, 29, 29+ compatible.

Size: available in two sizes. M/L and S.

Fork:          Fox / RockShox.

Wheels:    27.5 “

Maximum lateral tilting: greater than 50° (120% gradient).

Crank set: Schlumpf Drive mountain drive.

Gear:        1000% gear range or greater

Brakes:     front hydraulic, rear mechanical with two brake levers.

Seatpost:  dropper

Sizes v2.png
Sizes chart.png

Bear in mind that the geometry of the bike is not conventional, the head tubes are ahead of the actual lower handlebar that goes backwards and downwards. Changing the position or the shape of the lower handlebar changes the effective stack and reach. Also, the upper handlebar can be moved forward or backwards in a great extent.
